JLSFT R760 V7 Server
Classification:
R760 V7 is our own brand server with high performance, we can also supply OEM service for you.
Contact:
Features
Specifications
| Form Factor | 2U Rackmount Server | |||||||
| Processor | Processor Supports 2x4th/5th Generation Intel 8 Xeon⑧ Scalable Processors, TDP385W | |||||||
| Memory | 32 DDR5 memory slots, up to 5600MHz, supports multiple protection modes such as memory mirroring, memory hot standby, memory fault isolation, and supports additional expansion of 16 memory slots through CXL | |||||||
| Storage Controller | Storage controller Supports multiple storage solutions such as pass-through, RAID0, 1, 10, 5, 50, 6, 60 When configuring the RAlD controller, it can support Cache supercapacitor protection, provide RAD level migration, disk roaming, self-diagnosis, Web remote settings and other functions, and support RAID card safe startup | |||||||
| Storage | Front: supports up to 12 3.5-inch or 24 2.5-inch hard drives, compatible with NVMe hard drives Built-in: supports 2 SATA/PCle M.2, 1 onboard eMMC chip | |||||||
| Network Ports | OCP3.0 network card, with NCSI function, optional 2*1GE, 2*10GE, 2*25GE, 2*100GE, 2*2OOGE and other interfaces | |||||||
| PCI Expansion | Up to 9 PCle 5.0 expansion slots can be configured, including 1 OCP slot Maximum support for double-width GPU*4 | |||||||
| Other Interfaces | Rear of the chassis: 1 RJ45 management interface, 2 USB3.0 interfaces, 1 VGA interface Front of the chassis: 2 USB3.0+VGA or USB2.0 optional Inside the chassis: 1 built-in USB 3.0 interface | |||||||
| Power | Optional 2000W/2200W/2700WCRPS high-efficiency platinum hot-swappable power supply, support 1+1 redundancy, voltage range 100-240Vac (please refer to the power input value on the host nameplate label) | |||||||
| Cooling | 6 hot-swappable fan modules, support N+2 redundancy | |||||||
| Management function | Integrated BMC chip, provides one 1GbpsR45 management port, supports standard interfaces such as Redfsh, SNMP, IPMI2.0, and remote management interface based on KVM/HTML5, provides comprehensive fault diagnosis, automated operation and maintenance, and remote management functions, and supports BMC dual flash redundant backup | |||||||
| Operating System | Microsoft Windows Server、RedHat Enterprise Linux、SUSE Linux EnterpriseServer、CentOS、Ubuntu、VMware EXSI、Kylin、Redflag , etc | |||||||
| Operating Temperature | 5℃~35℃(Please consult the company for details) | |||||||
| Dimensions | 770mm (length) x446mm (width) (excluding box ears) x87mm (height) 770mm (length) x482mm (width) (including box ears) x87mm (height) | |||||||
| Weight | Maximum weight 45kg. | |||||||
